Description
The E232T8IS120/N/AS Electronic Instant Start Ballast offers reliable and efficient performance for T8 fluorescent and compatible LED lamps. Designed for parallel lamp connections and operating on 120V, this ballast ensures consistent performance with instant start capability and high thermal protection.
Ideal for both commercial and residential retrofit applications, it operates in temperatures as low as -18°C and features a Class P thermal protection with a maximum case temperature of 75°C. Backed by a 5-year warranty, it’s a durable solution for lighting installations requiring energy efficiency and long-term reliability.
Key Features:
✅ Electronic Instant Start Ballast – Efficient, fast startup for T8 lamps
✅ Parallel Lamp Connection – Operates 1-2 lamps efficiently
✅ Versatile Compatibility – Supports a wide range of lamp types, including F32T8, F25T8, F17T8, and compatible LED T8s
✅ High Power Factor (0.92-0.98) – Delivers reliable energy efficiency
✅ Low THD (10-15%) – Ensures clean and stable operation
✅ Wide Temperature Range – Operates in temperatures as low as -18°C
✅ Thermal Protection – Rated for a maximum case temperature of 75°C
✅ 5-Year Warranty – Backed by a manufacturer’s guarantee for peace of mind
✅ Energy Efficient – Meets stringent performance standards for energy savings
⚙️ Technical Specifications:
| Feature | Details |
|---|---|
| Ballast Type | Electronic, Instant Start (IS) |
| Lamp Connection | Parallel |
| Input Voltage | 120V |
| Input Frequency | 60Hz |
| Max Case Temperature | 75°C |
| Thermal Protection | Class P |
| Certifications | cULus, Energy Star |
| Warranty | 5 Years (75°C) / 3 Years (90°C) |
✅ Compatible Lamp Types & Performance
| Lamp Type | Lamps | Wattage | Min Start Temp (°C) | Ballast Factor | Input Power (W) | Power Factor |
|---|---|---|---|---|---|---|
| F32T8 | 2 | 32W | -18°C | 0.87 | 55 | 0.98 |
| F32T8/ES | 2 | 28-30W | -18°C | 0.87 | 48-52 | 0.98 |
| F25T8 | 2 | 25W | -18°C | 0.90 | 49 | 0.97 |
| LED22T8 | 2 | 22W | -18°C | - | 45 | 0.97 |
| LED18T8 | 2 | 18W | -18°C | - | 40 | 0.95 |
| F17T8 | 2 | 17W | -18°C | 0.92 | 34 | 0.92 |
| F32T8 | 1 | 32W | -18°C | 1.11 | 38 | 0.92 |
| F40T8 | 1 | 40W | 0°C | 1.00 | 45 | 0.92 |
Ideal for:
- Commercial and Industrial Lighting – Efficient operation in ceiling fixtures, troffers, and more
- Retrofit Projects – Update older ballasts with modern, efficient technology
- Cold Start Environments – Reliable performance down to -18°C
- Energy-Efficient Installations – For facilities focused on reducing energy consumption
⚠️ Important Installation & Return Notice:
- Check Compatibility: Please review the technical specifications to ensure compatibility with your lamps and fixtures.
- Returns Policy: We cannot accept returns for ballasts that have been installed. Installation may compromise the product, and we cannot verify its integrity once installed. Please double-check compatibility before installation.
